When it comes to installing your new flat-screen TV, one of the most overlooked but absolutely crucial details is choosing the right screw size for your TV mount. Ask any homeowner who’s tried to mount their TV only to realize they don’t have the correct screws—it’s frustrating, time-consuming, and can even damage your wall or TV if done incorrectly.
So, what size screws do you actually need for a TV wall mount? The answer depends on several factors: your TV’s VESA pattern, the type of TV mount you're using, the wall material, and the thickness of the mounting bracket.In this guide, we’ll break down everything you need to know about screw sizes for various types of TV mounts, including tv mount ceiling, automated tv mount, tv mount drop down, and floor stand tv mount options. We’ll also showcase high-quality mounts from trusted TV mount supplier Jieyong Industrial, helping you avoid guesswork and get your TV securely mounted the first time.
Using the wrong screw size when installing a TV mount can lead to serious issues. Screws that are too short won’t hold the weight of your TV, while screws that are too long can damage internal components. The right screw size ensures stability, safety, and long-term durability of your tv wall mount setup.
TVs have standardized mounting hole patterns called VESA (Video Electronics Standards Association). These patterns not only determine the spacing between holes but also influence the screw size required to secure your TV to the TV mount.
Most TVs today follow the VESA standard for mounting hole patterns. Common VESA sizes include 100x100mm, 200x200mm, 400x400mm, and so on. Each VESA size corresponds with specific screw types, most often metric screws.
| VESA Size (mm) | Compatible Screw Type | Typical TV Size |
|---|---|---|
| 100x100 | M4 x 10-20mm | 19-24 inch TVs |
| 200x200 | M6 x 10-20mm | 26-43 inch TVs |
| 400x400 | M8 x 20-45mm | 46-65 inch TVs |
| 600x400 | M8 x 25-50mm | 65 inch and up |
Note: The screw length you need may vary slightly depending on the thickness of your tv wall mount bracket or adapter plate.
Not all TV mounts are created equal. Depending on the design and application, certain mounts may require additional hardware or longer screws. Below are some of the most common types of TV mounts and their hardware considerations:
This is the most common mounting style. Whether it's a fixed or tilt bracket, most china tv wall mount models from Jieyong Industrial are compatible with M6 or M8 screws for TVs 32 inches and larger. For example, their Full Motion Swivel TV Mount supports VESA up to 600x400mm and includes M8 fittings.
A tv mount ceiling option like Jieyong’s foldable ceiling bracket requires screws not only for the TV but also for anchoring into the ceiling joists. Lag bolts or expansion screws are often used for the ceiling, along with M6 or M8 screws for the TV interface. Some tv mount drop down models include cable management and require slightly longer screws to account for the extra bracket thickness.
A floor stand tv mount is a freestanding solution that often includes a universal bracket. These are compatible with M6 and M8 screws, depending on the TV size. Jieyong’s adjustable mobile TV cart includes multiple screw types in the package, suitable for VESA from 200x200 to 600x400.
For smart setups, an automated tv mount or remote control tv mount will usually include motor housing and additional components. These may require longer M8 screws for the added bracket depth. Jieyong’s motorized mounting solutions come with a complete screw kit for hassle-free installation.
Jieyong Industrial is a leading tv mount supplier based in China, offering a wide selection of mounting solutions for residential and commercial use. Here’s how some of their top products stack up when it comes to screw compatibility and installation:
| Product Name | Mount Type | VESA Range | Screw Size Included | Special Features |
|---|---|---|---|---|
| JY-D40 Full Motion Swivel TV Mount | Wall Mount | 100x100–400x400 | M6, M8 | Swivel, tilt, cable management |
| JYPT-060 Motorized Ceiling Mount | TV Mount Ceiling | 200x200–600x400 | M8 | Motorized drop-down, remote control |
| JYLCD-261 Mobile Floor Stand | Floor Stand TV Mount | 200x200–600x400 | M6, M8 | Wheels, AV shelf, height adjustable |
| JY-A41 Fixed Wall Bracket | TV Wall Mount | Up to 400x400 | M6 | Low profile, ultra slim design |
| LCD-B70 Slim Fixed Mount for 40–70 inch TVs | TV Wall Mount | Up to 600x500 | M8 | 55kg capacity, safety lock mechanism |
Don’t overtighten: Screws should be firm but not forceful. Over-tightening can strip the threads or crack the mounting points.
Use washers if needed: Some brackets come with oversized holes, and washers can help distribute pressure evenly.
Match screw length to bracket thickness: If your tv wall mount has a thick backplate, use longer screws to compensate.
Use anchors for drywall: Never mount directly into drywall without anchors or studs. Use toggle bolts or wall anchors for safety.
Most high-quality tv mount kits from reputable suppliers like Jieyong include a universal screw kit with various sizes. But if you’re purchasing screws separately, make sure to have:
M4, M6, and M8 screws (10mm–50mm)
Washers for each screw type
Wall anchors or lag bolts (for wall/ceiling mounting)
Allen keys or screwdrivers as required
If you’re unsure, consult your TV’s manual and the mount’s installation guide—most will specify the exact screw size needed.
As TVs get slimmer and homes smarter, mounting technology evolves. Newer trends include:
Automated tv mount systems with programmable memory positions
Remote control tv mount models for easy adjustment
Voice-controlled tv mount ceiling systems integrated with smart home platforms
Hidden or retractable tv mount drop down options for minimalist spaces
These modern mounts often require additional spacer kits or custom screws due to their advanced designs. Jieyong’s motorized and smart mounts are built with these requirements in mind, and include all necessary hardware.
Choosing a reliable tv mount supplier like Jieyong ensures that you receive not only durable mounting brackets but also the correct screw kits and installation support. Jieyong Industrial has over 20 years of experience in the industrial tv mount field, combining advanced production technology, precision engineering, and strict quality control.
Highlights of Jieyong as a china tv wall mount leader:
Certified manufacturing processes
OEM/ODM customization support
Full product range: from tv wall mount to tv mount ceiling and floor stand tv mount
Global supply chain with fast delivery
Whether you’re a homeowner, contractor, or distributor, working with a reputable supplier helps you avoid the headaches of mismatched parts and low-quality materials.
A1: What size screws are standard for mounting a TV?
Q1: The most common screw sizes are M4, M6, and M8. For TVs 32 inches and up, M6 and M8 are typically used. Always check your TV’s VESA pattern and weight to confirm.
A2: Can I use any screws for my TV mount?
Q2: No, always use the correct metric screws (M4, M6, M8) specified by your TV manufacturer. Using incorrect screws can damage your TV or cause it to fall.
A3: Do TV mount kits come with screws?
Q3: Yes, premium mounts from suppliers like Jieyong Industrial usually include a universal screw set with multiple sizes and washers. Budget kits may not.
A4: What screw size is needed for ceiling TV mounts?
Q4: For the TV interface, usually M6 or M8 depending on screen size. For the ceiling, use lag bolts or anchors appropriate to your ceiling material.
A5: How do I know if my screw is too long?
Q5: If the screw goes in too far and feels loose, it’s likely too long. It should tighten securely without resistance and without bottoming out.
A6: Is it safe to reuse old TV mount screws?
Q6: It’s best to use new screws that come with your mount. Reused screws may be worn or incompatible with your new TV’s VESA pattern.
Selecting the right screw size for your tv mount might seem like a small detail, but it’s one that can make or break your installation. Whether you're mounting a 55-inch Samsung on drywall, installing a tv mount ceiling in your kitchen, or setting up a floor stand tv mount in your office, getting the screw size right ensures a safe, clean, and stress-free setup.
Trusted tv mount supplier Jieyong Industrial makes this process easier by offering mount kits that include all necessary hardware, detailed instructions, and universal compatibility. Explore their full catalog today and discover high-quality mounting solutions for any application.
